Hummer 2005 H2 User Manual

Fuses Usage
IPC/DIC
Instrument Panel
Cluster/Driver Information
Center
HVAC/ECAS
Climate Control
Controller/Electronically
Controlled Air Suspension
CIG LTR Cigarette Lighter
HI HDLP-RT High Beam Headlamp-Right
HDLP-LOW Headlamp Low Beam Relay
A/C COMP
Air Conditioning
Compressor Relay
A/C COMP Air Conditioning Compressor
RR WPR Rear Wiper/Washer
RADIO Audio System
SEO B1
Mid Bussed Electrical
Center, HomeLink, Rear
Heated Seats
LO HDLP-LT Headlamp Low Beam-Left
BTSI
Brake Transmission Shift
Interlock System
Fuses Usage
CRNK Starting System
LO HDLP-RT Headlamp Low Beam-Right
FOG LP Not Used
FOG LP Not Used
HORN Horn Relay
W/S WASH
Windshield and Rear Window
Washer Pump Relay
W/S WASH
Windshield and Rear Window
Washer Pump
INFO OnStar
RADIO AMP Radio Amplifier
RH HID Not Used
HORN Horn
EAP Not Used
TREC All-Wheel Drive Module
SBA Not Used
5-111
