5©2010 Hunter Fan Co. 44091-01 20101005
Figure 1.
SETTING UP YOUR AIR PURIFIER
1. Take the Air Purifier out of the box and remove the
clear plastic protective bag and place the unit on a
firm, level surface.
2. Before turning on the Air Purifier, you need to confirm
that the filters are firmly in place and have not become
loose during shipping. To check the filters, push down
on the tab under the handle. Figure 1.
3. Gently pull the rear grill away from the unit and lift
away. Figure 2.
4. The washable Pre-Filter is mounted inside the back
grill of the unit. Confirm that it properly covers the
grill vents.
5. The Permanent HEPA Filter will be resting inside the
unit. If present, remove the plastic bag surrounding
the filter and place the filter back into the Air Purifier.
The filter should have arrows on the side to indicate
air flow and the direction the filter should be placed
back into the unit. Figure 3.
6. Set the tab on the bottom of the rear grill into the slot
in the base of the unit and rock the grill up until the
top tab snaps into place. Figure 4.
7. Plug the unit into a 120V electrical outlet.
Figure 2.
Figure 4.
Figure 3.
Permanent
HEPA Filter
Tab
To Next Page
