Switch Housing (continued)
Make sure the lower switch housing is securely attached to
the upper switch housing. Failure to properly secure all three
Connect the plugs from the upper and
lower switch housings. Make sure to line up
the colored markings on the connectors.
Partially install two of the switch housing
screws found in the hardware bag. Align
the notches in the sides of the switch housing
with the screws on the upper switch housing.
Twist the lower switch housing clockwise
to lock into place. Install the third switch
housing screw. Tighten all three screws.
Installing the pull chain pendant - Attach the
pull chain pendant to the short chain coming
from the switch housing.
14
