ACC2 STRONGBOX PEDESTAL ASSEMBLY INSTRUCTIONS
Assembly
Reassembling the Hunter ACC2 inner
chassis assembly: Deck assembly
(Decoder version shown)
Step 1: Install the deck assembly by inserting
the lower hooks and tilting back (Fig. 1).
• Make sure both cables on the le side are
outside of the deck assembly.
Step 2: Tighten the captive screws (qty: 2)
using #2 Phillips head screwdriver (Fig. 2).
Reassembly of Hunter Inner Chassis Assembly
Fig. 1 Fig. 2
