2
Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
x4
x2
x2
x2
For installing the hanger bracket and wiring the fan
For installing the canopy
Canopy Canopy
Screw
Ceiling Bracket
Wood Screw
Wire Nut
Washer
bag
Hunter Pro Tip:
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.
Monday - Friday 8am - 6pm CST. Saturday 11am - 4pm CST (English or Español)
Here is what comes in your box:
bag
For installing the blades
For your convenience,
you may receive extra fasteners.
bag
Downrod
M3999-01 r121322
For installing the light kit
Motor
Wall Control
Cap
Upper assembly
Blade
x5
x15
bag
Blade Screw
x15
bag
Blade Nut
x3
Upper Switch
Housing Screw
bag
x3
Switch Housing
Screw
Fan style may vary.
Note:
To Next Page
