SECTION 2
OPERATING INSTRUCTIONS
2-1. Introduction
This section describes the basic operation of the Tracker 2700 and 2700S.
2-2. Unpacking Your Instrument
Your Tracker 2700 or 2700S was shipped with the following items:
QTY DESCRIPTION HUNTRON P/N
1 Manual (CD) 06-5217
1 Power Cord 98-0265
2 Common test leads (black) 98-0043
1 Shrouded Test Lead (blue) 98-0284
1 Huntron Probe Set (red & black) 98-0249
Additional items with Tracker 2700S
QTY DESCRIPTION HUNTRON P/N
2 20 pin DIP clip cable 98-0290
2 40 pin DIP clip cable 98-0026
2 20 pin DIP clip 07-1234
2 40 pin DIP clip 07-1230
Check the shipment carefully and contact the place of purchase if anything is missing or
damaged in shipment. If reshipment is necessary, please use the original shipping carton and
packing foam. If these are not available, be sure that adequate protection is provided to prevent
damage during shipment.
To order any of the above items, or for further information, please contact Huntron.
2-3. General Operation
Components are tested by the Tracker 2700 using a two terminal system (three terminal system
when the built-in DC Voltage Source is used), where two test leads are placed on the leads of the
component under test. The Tracker 2700 tests components in-circuit using a test clip on a
common reference point, even when there are several components in parallel.
Note: All operational descriptions in this manual relate to both the Tracker 2700 and Tracker
2700S. The Tracker 2700S contains all features of the Tracker 2700. Features that are specific to
the Tracker 2700S will be noted when applicable.
CAUTION
To Next Page
