6-
23
Figure 6-32a shows the test setup for a PNP transistor. The displayed signature will be the result
of the collector-base junction of the transistor.
Figure 6-32a. DC Source Test Circuit for a PNP Transistor
DC Level = 0V DC Level = 5V
Fig 6-32b. Test Circuit Signatures for PNP Transistor
