English
7
WHA
T IS
WHA
T?
What is what on the c
learing saw? (250R)
29
23
25
26
24
21
4
1
18
1
3
2
6
8
9
7
4
5
16
10
11
12
15
14
13
22
19
20
28
17
27
1
Blade
2 Grease filler cap, bevel gear
3 Bevel gear
4 Cutting attachment guard
5 Shaft
6 Handlebar
7 Throttle control
8 Stop switch
9 Throttle lockout
10 Support eyes for harness
11 Cylinder cover
12 Starter handle
13 Choke control
14 Air filter
15 Fuel tank
16 Handle adjustment
17 Locking screw (support cup)
18 Support flange
19 Support cup
20 Drive disc
21 Socket spanner
22 Operator’s manual
23 Transport guard
24 Allen key
25 Carburettor screwdriver
26 Locking pin
27 Harness
28 Gearbox grease
29 Locking nut
