Husqvarna 2748 GLS - User Manual

Husqvarna 2748 GLS
44 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
2008-01
O0802013
2748 GLS
Operator's
Manual
Operator's Manual
Ride Mower
96043004600
03002

Questions and Answers

  • A
    Alexander HermanAug 13, 2025
    How to fix poor cut (uneven) from Husqvarna 2748 GLS?
    • T
      Tara HaynesAug 13, 2025
      If your Husqvarna Lawn Mower is providing a poor, uneven cut, several issues could be to blame. Check for worn, bent, or loose blades; replace them if necessary and tighten the blade bolt. Ensure that the mower deck is level. Buildup of grass, leaves, and trash under the mower can also cause this, so clean the underside of the mower housing. Finally, a bent blade mandrel can also be the reason, so consider replacing the blade mandrel. Also, clogged mower deck vent holes can cause an uneven cut, so clear them around the mandrels.
  • J
    Jeffery ThomasAug 16, 2025
    What causes the battery of Husqvarna 2748 GLS to not charge?
    • K
      Kristen WallaceAug 17, 2025
      If the battery of your Husqvarna Lawn Mower will not charge, it could be due to several reasons. The battery may have bad cell(s) and need replacement. Check for poor cable connections and clean them. If the issue persists, the regulator (if equipped) or the alternator might be faulty and require replacement.
  • G
    Gregory GillespieAug 20, 2025
    Why are the headlights not working on my Husqvarna 2748 GLS?
    • J
      Julie MendezAug 21, 2025
      If the headlights on your Husqvarna Lawn Mower are not working, there are several potential causes. First, ensure the light switch is turned “ON”. If the switch is on, the bulb(s) or lamp(s) may be burned out and need replacement. A faulty light switch or loose/damaged wiring could also be the culprit, requiring a check and replacement if necessary. Finally, check if the fuse is blown and replace it if needed.
  • H
    Heather WarnerAug 25, 2025
    Why does my Husqvarna 2748 GLS Lawn Mower have poor grass discharge?
    • L
      lscottAug 25, 2025
      If your Husqvarna Lawn Mower exhibits poor grass discharge, several factors could be responsible. Start by ensuring the engine speed is set to “FAST” and that your travel speed isn't too fast; shift to a slower speed if necessary. Wet grass can also cause this issue, so allow the grass to dry before mowing. Additionally, check that the mower deck is level and the tire air pressure is correct. Other potential causes include worn, bent, or loose blades (replace/sharpen and tighten), buildup of grass under the mower (clean the underside), a worn mower drive belt (replace it), improperly installed blades (reinstall with the sharp edge down), using improper blades (replace with the correct ones), or clogged mower deck vent holes (clean around the mandrels).
  • S
    Sarah CollinsAug 28, 2025
    What to do if Husqvarna 2748 GLS Lawn Mower engine dies when shifted into reverse?
    • M
      Meghan TaylorAug 28, 2025
      If the engine of your Husqvarna Lawn Mower dies when shifted into reverse, it's likely that the Reverse Operation System (ROS) is not "ON" while the mower or other attachment is engaged. To resolve this, turn the ignition key to the ROS "ON" position. See the Operation section for detailed instructions.
  • A
    Ashley MartinezSep 1, 2025
    Why won't the mower blades rotate on my Husqvarna 2748 GLS?
    • J
      Jocelyn RossSep 1, 2025
      If the mower blades on your Husqvarna Lawn Mower will not rotate, there might be an obstruction in the clutch mechanism that needs to be removed. Alternatively, the mower drive belt could be worn or damaged and require replacement. Other potential issues include a frozen idler pulley or a frozen blade mandrel, both of which would need to be replaced.
  • L
    Lori SmithSep 4, 2025
    Why am I experiencing loss of drive on my Husqvarna 2748 GLS Lawn Mower?
    • J
      jbernardSep 4, 2025
      If you experience a loss of drive with your Husqvarna Lawn Mower, ensure the freewheel control is in the “engaged” position. If it is already engaged, the motion drive belt may be worn, damaged, or broken, requiring replacement. Additionally, air trapped in the transmission during shipment or servicing can cause this issue, so you may need to purge the transmission.
  • M
    Michelle CaldwellSep 8, 2025
    What to do if Husqvarna Lawn Mower engine runs when I leave the seat?
    • A
      Amber RojasSep 8, 2025
      If the engine of your Husqvarna Lawn Mower continues to run when the operator leaves the seat with the attachment clutch engaged, this indicates a faulty operator-safety presence control system. Check the wiring, switches, and connections. If the issue is not resolved, contact an authorized service center/department.

Summary

SAFETY RULES

I. GENERAL OPERATION

Instructions for general operation of the tractor.

II. SLOPE OPERATION

Guidelines for safe operation on slopes.

V. SERVICE

Information on safe handling of gasoline and general service.

SAFE HANDLING OF GASOLINE

Precautions for handling gasoline safely.

PRODUCT SPECIFICATIONS

OPERATION

HAZARD SYMBOL DEFINITIONS

Explanations of DANGER, WARNING, CAUTION, HOT SURFACES, and FIRE symbols.

OPERATION Controls and Adjustments (Fig. 3)

Identification and function of tractor controls and adjustments.

TO ADJUST MOWER CUTTING HEIGHT

Steps to adjust the cutting height of the mower deck.

TO OPERATE MOWER

Instructions for engaging and operating the mower.

REVERSE OPERATION SYSTEM (ROS)

Explanation and use of the Reverse Operation System.

TO OPERATE ON HILLS

Guidelines for safely operating the tractor on hills.

ADD GASOLINE

Instructions for safely adding gasoline to the tractor.

TO START ENGINE

Procedures for starting the engine in different weather conditions.

MOWING TIPS

Advice for optimal mowing performance and results.

MAINTENANCE

MAINTENANCE SCHEDULE

A schedule of maintenance tasks and their frequency.

OPERATOR PRESENCE SYSTEM AND REVERSE OPERATION SYSTEM (ROS)

Checking the functionality of safety systems.

TO CHANGE ENGINE OIL

Detailed steps for changing the engine oil.

SERVICE AND ADJUSTMENTS

WARNING: TO AVOID SERIOUS INJURY...

General safety precautions before performing service.

TROUBLESHOOTING POINTS

Will not start

Causes and corrections for the engine not starting.

Hard to start

Causes and corrections for difficulty starting the engine.

Engine will not turn over

Causes and corrections for the engine not turning over.

Loss of power

Causes and corrections for the engine losing power.

Poor cut - uneven

Causes and corrections for uneven grass cutting.

Mower blades will not rotate

Causes and corrections for mower blades not rotating.

ELECTRICAL

CHASSIS

DRIVE

STEERING ASSEMBLY

ENGINE

MOWER DECK

MOWER LIFT

SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION

Husqvarna 2748 GLS Specifications

General IconGeneral
BrandHusqvarna
Model2748 GLS
CategoryLawn Mower
LanguageEnglish
