Husqvarna R 214TC - User Manual

R 214T, R 214TC, R 214TC Comfort Edition,
R 216T AWD
EN Operator's manual 2-34
ES Manual de usuario 35-70
IT Manuale dell'operatore 71-106
PT Manual do utilizador 107-142

Husqvarna R 214TC Specifications

General

Engine Manufacturer	Briggs & Stratton
Cylinders	1
Cutting Width	94 cm
Cutting Height Min	25 mm
Cutting Height Max	75 mm
Transmission Type	Hydrostatic
Drive Method	Rear-Wheel Drive
Engine Cooling	Air
Fuel Type	Gasoline
Engine Lubrication Type	Full pressure
Oil Filter	Yes
Transmission Manufacturer	Tuff Torq
Drive	Rear-wheel drive
Speed Forward, min-max	0-9 km/h
Uncut Circle	30 cm
Blade Engagement	Manual
Blades	3
Seat Material	Vinyl
Hour Meter Type	Digital
Parking Brake, Type	Disc
Cutting Methods	BioClip®/Rear discharge
Wheel Size Rear	170/60-8

Summary

Introduction to the Husqvarna Ride-On Mower

Pre-Delivery Inspection and Product Identification

Details about pre-delivery inspection and product identification.

Product Description, Intended Use, and Insurance

Overview of product features, purpose, and insurance advice.

Product Overview and Component Identification

Key Component Identification (1-17)

Identifies and describes key components and controls of the product.

Electrical System and Operation Basics

Electrical System Overview and Operation Controls

Details electrical components, pedals, hour meter, and cutting deck operation.

Operator Presence Control (OPC) System

Explains the safety system that stops the engine when the operator leaves the seat.

Product Symbols and Safety Warnings

Understanding Product Symbols

Explains safety warnings and operational symbols used on the product.

Safety Information and Definitions

Safety Definitions and General Guidelines

Defines safety terms and provides essential general safety guidelines.

Electromagnetic Field Safety Warning

Warns about electromagnetic fields and their potential interference with medical implants.

Operational Safety and Child Protection

Child Safety and Safe Operating Practices

Safety measures to protect children and safe operating practices.

Safety Device Checks and Starting Requirements

Safety Device and Component Functionality Tests

Procedures for checking safety devices, ignition lock, pedals, and parking brake.

Engine Start Conditions

Lists necessary conditions before the engine can be started.

Specific Operational Safety and Fuel Handling

Cutting on Slopes and Fuel Safety

Guidelines for cutting grass on slopes and safe fuel handling.

System Safety and Maintenance Precautions

Battery, Maintenance, and Exhaust Safety

Safety guidelines for battery, maintenance, and engine exhaust.

Assembly Procedures

Cutting Deck Assembly and Belt Spring Warning

Instructions for attaching the cutting deck and a warning about the drive belt spring.

Product Operation and App Integration

Pre-Operation Checks, App Setup, and Fueling

Covers pre-operation checks, app setup, and fueling procedures.

Seat and Steering Wheel Adjustment

Guides for adjusting seat position and steering wheel height.

Operation Controls

Drive System and Cutting Deck Control

Explains engaging drive, and lifting/lowering the cutting deck.

Starting and Operating the Mower

Engine Starting and Mower Operation

Step-by-step guide for starting the engine and operating the product.

Operation Completion and Maintenance Introduction

Stopping, Brake, Cutting Tips, and Maintenance Overview

How to stop, brake, get good cuts, and an introduction to the maintenance schedule.

Maintenance Schedule: Product Preparation and Engine

Product Preparation and Engine Servicing Tasks

Specific maintenance tasks for product preparation and engine servicing.

Maintenance Schedule: Systems, Cutting Deck, and Cleaning

Transmission, Cutting Deck, and Cleaning Procedures

Maintenance for transmission/cutting deck and product cleaning procedures.

Cleaning Procedures for Components

Engine, Muffler, Air Intake, and Cover Cleaning

How to clean engine, muffler, air intake, and remove covers.

Component Removal and System Checks

Part Removal, Steering Check, and Fuel Filter Replacement

Procedures for removing covers, checking steering, and replacing the fuel filter.

Engine Component Service

Spark Plug and Main Fuse Service

How to examine/replace spark plugs and the main fuse.

Electrical System Service and Emergency Start

Lamp Replacement, Battery Charging, and Emergency Start

Replacing lamps, charging batteries, and emergency engine starting.

Emergency Procedures and Tire Maintenance

Jumper Cables, Tire Pressure, and Deck Servicing Position

Connecting jumper cables, tire pressure specs, and preparing the cutting deck.

Cutting Deck Adjustments and Checks

Mow Position, Ground Pressure, and Parallelism Adjustments

Adjusting mow position, ground pressure, and checking cutting deck parallelism.

Cutting Deck Parallelism and BioClip Plug Service

BioClip Plug Removal and Attachment Procedures

Adjusting deck parallelism and servicing the BioClip plug.

Blade and Engine Oil Maintenance

Blade Inspection, Replacement, and Engine Oil Check

How to inspect, replace blades, and check engine oil level.

Engine Oil and Filter Replacement

Engine Oil and Filter Change Procedure

Detailed steps for replacing engine oil and oil filter.

Transmission and Belt Adjuster Maintenance

Transmission Oil Check and Belt Lubrication

How to check transmission oil and lubricate the belt adjuster.

Troubleshooting Common Issues

Engine, Transmission, and Vibration Problems

Addresses common issues with engine, transmission, and vibration.

Transportation, Storage, and Disposal

Transportation, Storage, and Fuel Handling Safety

Guidelines for transporting, storing, and fuel handling safety.

Disposal Guidelines

Chemical, Product, and Battery Disposal

Procedures for disposing of chemicals, products, and batteries responsibly.

Technical Data: Dimensions and Engine

Product Dimensions and Engine Specifications

Specifications for the product's physical dimensions and engine details.

Technical Data: Performance and System Specifications

Performance, Electrical, and Cutting Deck Specs

Data on speed, oil, electrical systems, battery, and cutting deck types.

Technical Data, Service, and Warranty

Noise, Vibration, Service, and Warranty Information

Data on noise/vibration, service recommendations, and warranty details.
