CONTENTS OF HARDWARE PACK
Parts packed separately in carton
Parts Bag contents shown full size
Parts bag contents not shown full size
(2) Hex Bolts 1/4-20 x 3/4
(2) Washers
9/32 x 5/8 x 16 Ga.
(2) Lock
Washers 1/4
(2) Hex Nuts
1/4-20
Seat
Manual
Steering
Wheel
Parts Bag
(2) Weld
Nuts #10
(2) Washers
3/16 x 3/4 x 16 Gauge
(2) Screws
#10 x 5/8
(2) Lock
Washers #10
Nose Roller
Nose
Roller
Brackets
(2) Latch Hook
Assemblys
Steering
Wheel
Adapter
(2) Keys
Steering
Wheel Insert
(2) Hex Bolts
3/8-16 x 1
(2) Washers
17/32 x 7/8 x 16 Ga.
(2) Nylon
Locknuts 3/8-16
Mulcher
Plate
Front
Bumper
(2) Bumper Caps
(2) Reinforcement
Plates
Steering
Extension
Shaft
Slope Sheet
(1) Large Flat Washer
(1) Locknut
5/16-18
(1) Hex Bolt 5/16-18 x 1-1/4
(1) Hex Bolt
3/8-16 x 1
(1) Lockwasher 3/8
Steering
Sleeve
(1) Shoulder
Bolt 5/16-18
(1) Washer 17/32 x 1-3/16 x 12 Gauge
(1) Lock
Washer 1/2
(1) Hex Bolt 1/2-13 x 1
(
2) Shoulder
Bolts
(2) Gauge
Wheels
(2) Washers 3/8
x 7/8 x 14 Gauge
(2) Center-
lock Nuts
(2) Hex Bolts 3/8-16 x 1
(2) Front Link Assemblies
