5
UNASSEMBLED PARTS
Steering
Wheel Insert
Steering Wheel
(1) Knob
(1) Washer
17/32 x 1-3/16 x 12 Gauge
Seat
(2) Keys
Slope Sheet
Steering
Adapter
(1) Oil Drain Tube
(4) Washers
3/8x3/4x14Ga.
(4) Wheels
(4) Adjusting Bar
(4) Retainer Springs
(double loop)
(4) Clevis Pins
(4) Locknut 3/8-16
(4) Shoulder Bolt
Steering Sleeve
(2) Hex Bolts 1/4-20 x 3/4
(2) Keps Nut 1/4-20
Battery
Gauge Wheels
