114443_1011 2-5
Footrest
INDEX NO. PART NO. QTY. DESCRIPTION
1 550986 1 FLOOR PLATE (WITH TREADS & DECALS)
2 602920 1 FWD-REV DECAL
3 112852 1 FOOT PAN STEP TREAD
4 602915 1 PARK BRAKE DECAL
5 603364 1 LEFT STEP TREAD
6 808485 6 RIVET NUT, 5/16-18 THREAD
7 768523 9 FW .343 X .687 X .051/.080H
8 602727 10 CS .312-18 X 1.0 BHSK ZNYC
9 601069 13 CN .312-18 X .200 MAX THK
10 114392 1 FLOOR PLATE EXTENSION
11 550984 1 RS FLOOR COVER (WITH TREAD)
12 112851 2 STEP TREAD, COVER
13 550985 1 LS FLOOR COVER (WITH TREAD)
14 034280 9 CS .312-18 X .750 HX G5
15 033035 21" WEATHERSTRIP .12 X .75
NOTES:
