114443_1011 3-3
Steering Wheel Support
INDEX NO. PART NO. QTY. DESCRIPTION
1 112050 1 STEERING TUBE
2 768259 2 BUSHING
3 602924 1 STEERING DECAL
4 068023 1 CS .500-13 X 3.750 HX G8
5 767962 2 FW .531 X 1.063 X .090 SAE
6 781567 1 NT .500-13 HX G8 ZY NL
7 601059 1 KNOB
8 112057 1 PIVOT HANDLE
9 078386 1 FW .510 X 1.750 X .18 ZNYC
10 263517 1 BEARING DISC
11 705954 1 CS .500-13 X 1.250 HX G5 ZN
12 602899 1 STEERING WHEEL CAP
13 021634 1 NT .625-18 HX PN
14 602426 1 STEERING WHEEL
15 034280 3 CS .312-18 X .750 HX G5
16 768523 7 FW .343 X .687 X .051/.080H
17 808485 3 RIVET NUT, 5/16-18 THREAD
18 036236 4 CS .312-18X1.000 HX G5
19 112059 1 BRACKET
20 601069 4 CN .312-18X.200 MAX THK
21 602569 1 STEERING COVER
22 739144 4 CS M 6-1.0 X 12 10.9 HX
23 602420 1 STEERING UNIT
24 603416 1 SEAL KIT–STEERING UNIT
NOTES:
1. Do not torque nut; it should be snug but allow the steering tube to pivot
freely.
