Drive Linkage
INDEX NO. PART NO. QTY. DESCRIPTION
1 602610 1 CABLE, PUSH/PULL 2"STRK
2 036384 1 SPRING 1/4 COIL PL 1.23
3 038828 1 CS .312-18 X 2.250 HX G5
4 112497 1 PIVOT CAM STUD
5 112496 1 CENTERING LEVER
6 603262 1 BUSHING, 1.00 I.D.
7 017616 1 CS .500-13 X 1.750 HX G5
8 602631 1 BEARING
9 718288 5 FW .516 X .875 X .09 ZNYC
10 112493 1 CONTROL LEVER ARM
11 008193 1 NT .500-13 HX G5 ZNYC
12 028035 5 CS M 8-1.25 X 20 HX G8.8
13 712927 1 FW .344 X 1.00 X.12 HRD Z
14 602867 1 SPACER, 1.00 OD X .109
15 602630 2 ROD END W STUD 1/4-28
16 058842 4 NT .250-28 HX JAM ZNYC
17 768515 11 FW .281 X .625 X .051/.080H
18 050161 2 CS .312-18 X 1.750 HX G5
19 034272 9 NT .312-18 HX G5 ZNYC
20 768523 16 FW .343 X .687 X .051/.080H
21 063198 2 CS 10-24 X .750 HXFLK ZN
22 602538 1 SWITCH PLUNGER, NC/NO
23 704916 1 CS .250-20 X 1.250 HX G5
24 024927 5 NT .250-20 HX GR.5 ZNYC
25 112492 1 BASEPLATE
26 601822 1 NUT PLATE, .420 CENTERS
27 058776 1 NT .312-18 HXZY NL
NOTES:
1. Part of cable.
