114443_1011 3-11
Rear Steering Fork
INDEX NO. PART NO. QTY. DESCRIPTION
1 602726 1 VINYL CAP
2 705954 1 CS .500-13 X 1.250 HX G5 ZN
3 602668 1 FW .531 X 2.5 X .134
4 602425 2 ROLLER BEARING
5 047704 1 CS .625-11 X 3.500 HX G5
6 025296 5 FW .760 X 1.625 X .08 ZNYC
7 015495 1 GREASE FITTING STRAIGHT
8 115157 1 BUSHING, STEER CYLINDER
9 045765 1 FW 1.030 X 1.500 X .134 ZN
10 115839 1 GREASE SHIELD
11 602417 1 STEERING CYLINDER
12 016725 1 CS .750-10 X 2.500 HX ZNY
13 602721 1 ROD END
14 061101 1 NT .750-10 HXZY NL
15 036855 1 NT .750-16 HX ZNYC
16 111976 1 CASTER FORK
17 728030 1 FW .656 X 1.312 X .090 ZNY
18 058768 1 NT .625-11 HXZY NY
19 008193 4 NT .500-13 HX G5 ZNYC
20 767962 8 FW .531 X 1.063 X .090 SAE
21 112138 1 SPINDLE
22 074252 4 CS .500-13 X 1.500 HX G5
23 602526 1 SPINDLE HUB
24 602533 5 WHEEL STUD
25 602527 1 SEAL
26 603410 1 HUB BEARING, RACE KIT (INCLUDES SEAL)
27 602532 1 HUB
28 602529 1 DUST CAP
29 061077 5 LUG NUT
30 602525 1 COTTER PIN
31 602524 1 WASHER
32 602523 1 SHAFT NUT
NOTES:
