Brake
INDEX NO. PART NO. QTY. DESCRIPTION
1 602384 2 HUB ASSY (WITH STUDS)
2 602383 2 BRAKE ASSY
3 064014 8 CS .312-18 X .875 HX G5 ZN
4 768523 24 FW .343 X .687 X .051/.080H
5 034272 10 NT .312-18 HX G5 ZNYC
6 036236 8 CS .312-18 X 1.000 HX G5
7 063297 2 SB .375 X .500 SH .312-1
8 018960 3 SPRING
9 715599 2 CS 10-24X1.000 HX G5 ZN
10 035626 4 NT #10-24 HX ZN
11 114026 2 BRAKE ARM
12 114193 2 CONDUIT HOLD DOWN
NOTES:
1. Included with wheel motor.
2. Torque to 220–240 ft-lbs.
3. Torque to 17 ft-lbs.
To Next Page
