Fuel System
INDEX NO. PART NO. QTY. DESCRIPTION
9 602702 1 FUEL TANK
10 602703 1 REAR COVER
11 602916 1 RATCHETING GAS CAP, 3.5"
12 714998 2 MS #10-24 X .625 HX ZN
13 773523 1 KEEPER, FLEXDRAW #37-25
14 704932 2 FW .219 X .500 X .048 ZNYC
15 059832 2 NT #10-24 HX NL ZN
16 773416 1 FLEX DRAW LATCH
17 601089 2 RIVET .188 DIA BLK HD
18 033001 3.25’ TRIM
19 601069 2 CN .312-18 X .200 MAX THK
20 113273 1 COVER LATCH PLATE
21 768523 4 FW .343 X .687 X .051/.080H
22 036236 4 CS .312-18 X 1.000 HX G5
23 808485 2 RIVET NUT, 5/16-18 THREAD
24 113275 1 REAR COVER MOUNT
25 712919 3 FW .406 X 1.00 X.12 HRD Z
26 000331 1 WIRE TIE, SMALL/SHORT
27 115684 1 FUEL TANK SUPPORT
28 603161 1 VACUUM BREAKER FILTER
29 603158 1 ROLLOVER VALVE & GROMMET
30 785295 1 SUCTION HOSE GROMMET
31 601527 1 SUCTION HOSE 19.5
NOTES:
CUT TRIM LENGTHS
A
3" TWO (2) PIECES
B
10" TWO (2) PIECES
C
13" ONE (1) PIECE
To Next Page
