Front Lift Arm
INDEX NO. PART NO. QTY. DESCRIPTION
1 114292 1 RS FRONT STABILIZER
2 114293 1 LS FRONT STABILIZER (NOT SHOWN)
3 601084 2 SB .750 X 2.000 SH.625-11
4 025296 6 FW .760 X 1.625 X .08 ZNYC
5 781153 4 BUSHING
6 016972 2 NT .625-11 HX G5 ZNYC
7 052837 8 CS .312-18 X 1.500 HX G5
8 712927 14 FW .344 X 1.00 X.12 HRD Z
9 113886 4 REEL LIFT CHAIN
10 034272 8 NT .312-18 HX G5 ZNYC
11 768523 26 FW .343 X .687 X .051/.080H
12 041152 4 NT .312-24 HX ZNYC
13 770867 4 BUSHING
14 602418 2 SINGLE ROD CYLINDER
15 603083 2 NT .750-16 HX G5 ZN JAM
16 754358 4 SB .375 X .375 SH .312-18
17 601507 2 FW .406 X 1.000 X .06 NYLON
18 114302 2 LIFT ARM DOG BONE
19 603308 2 LIFT YOKE
20 765339 2 BUSHING
21 034280 4 CS .312-18 X .750 HX G5
22 602539 4 BUSHING .625 I.D.
23 706143 2 NT .312-18 HX JAM GR5 ZY
24 114281 1 RS REEL LIFT
25 114291 1 LS REEL LIFT (NOT SHOWN)
26 781583 2 BRAKE ROD
27 602397 4 BUSHING, 1.00 I.D.
28 112005 1 RS FRONT LIFT ARM
29 112006 1 LS FRONT LIFT ARM (NOT SHOWN)
30 015495 6 GREASE FITTING STRAIGHT
31 054502 12 NT .375-16 HX GRD 5 ZNY
32 767954 20 FW .406 X .812 X .060 SAE
33 112136 1 REEL LIFT SPRING ANCHOR
34 112000 1 LIFT ARM RETAINER
35 601486 2 EB, .375-16 X 3.00 FULL THD
36 005132 2 CS .375-16 X 1.12 HX G5 Z
37 601016 2 IDLER SPRING
38 041855 2 SB .625 X 1.250 SH.500-13
NOTES:
1. Right side assembly is shown; left side assembly is similar.
