114443_1011 9-9
Rear Lift Arm
INDEX NO. PART NO. QTY. DESCRIPTION
36 016527 1 CS .500-13 X 1.00 HX G5 ZN
37 712976 1 FW .531 X 1.375 X .125 ZNY
38 113873 1 REAR CHAIN BRACKET
39 063552 2 CE .310 X 1.87 .150 X 1.73
40 705608 3 CS .250-20 X 2.25 HX G5 Z
41 768515 6 FW .281 X .625 X .051/.080H
42 068551 3 NT .250-20 HXZY NL
43 706549 2 HP .08 0D X 1.19
44 602865 1 .438 X 1.750 LYNCH PIN
45 045765 1 FW 1.030 X 1.500 X .134 ZN
46 601375 1 O-RING, SAE-14
47 112014 1 ROLLING ARM
48 112818 1 REAR REEL STOP
49 036244 4 CS .375-16 X 1.000 HX G5
50 112772 2 BASKET RETAINER
51 551015 1 REEL CARRIER (W/ DECAL)
52 058776 2 NT .312-18 HXZY NL
53 602925 1 REEL SAFETY DECAL
NOTES:
