1. Torque the cap screw to 45–48 ft-lbs.
Item Part No. Qty Name
1 601887 1 CB .375-16 X 2.25 STD ZN
2 016253 2 CB .312-18X .750 FUL ZN
3 126203-1 1 CLUTCH ANCHOR
4 607761 1 PULLEY, ENG 4.118OP
5 712372 1 KEY 1/4 SQ X 0.66 LG(FS)
6 607827 1 BUSHING, CLUTCH
7 016832 2 NT .312-18FLKG5
8 080655 1 CS .375-16X1.500HXG5
9 607757K 1 KIT, CLUTCH
10 607828 1 FW .468X1.625X.25 DD
11 602680 1 FW .453X1.12X.12 HRD ZN
12 785659 1 CS .437-20X2.50 HXG5 P85
13 767954 2 FW 0.379X.82X.06 HD ZN
14 607163 1 PULLEY, 3" FLAT POLY
15 607585 1 SPRING, EXTENSION
16 607837 1 TENSIONER
17 054502 1 NT .375-16HXG5
18 607763 1 SPACER, PIVOT IDLER
19 712893 1 FW 0.406X1.25X.12 HD ZN
20 086660 1 NT .375-16NLG8
21 607830 1 DRIVE BELT
Drive Belt & Clutch
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:33 UTC 2020 4-3
