Item Part No. Qty Name
1 607862 1 FENDER RIGHT
2 605473 12 CS .250-20X0.75 BH TX BZ
3 605628 10 FW 0.281X.63X.07 ZB
4 601982 4 CN .250-20X .150 MAX THK
5 555696 1 SVC, STEERING PLATE RH
Not Shown 555697 1 SVC, STEERING PLATE LH
6 785220 1 DECAL, STEERING R.S.
7 607913 2 HEX NUT CAP, 1/2"
8 058776 2 NT .312-18NLG5
9 607861 1 FENDER LEFT
10 785139 1 DECAL, STEERING L.S.
11 605782 1 DECAL, LEVEL FUEL BLOWM
12 555694 1 SVC, COVER FRONT
13 608095 1 DECAL, HUSTLER
14 055939 2 CS .250-20X0.75 HX G5 ZN
15 768515 3 FW 0.281SAE
16 126380-1 1 FOOTREST
17 555759 1 SVC, FLOOR PAN
18 607868 6 PUSH IN RIVET
19 607864 1 FLOOR MAT
20 056077 1 CS .250-20X1.000HXG5
21 555695 1 SVC, KICK PANEL
22 608093 1 DECAL, RAPTOR XD
23 781880 4 BUMPER, .500x 1.00x .31
24 118900 1 SPACER, DECK LIFT LINK
25 607892 8 CS #10-16 X 0.500 HX FLG
26 794784 2 CB .250-20 X .75 FUL ZN
27 016816 2 NT .250-20FLKG5
28 016832 8 NT .312-18FLKG5
29 607901-6 1 LOWER COVER
30 607903-1 1 ENGINE GUARD RH
31 607902-1 1 ENGINE GUARD LH
32 016253 8 CB .312-18X .750 FUL ZN
33 607906 2 SIDE MOLDING
34 068551 2 NT .250-20 HXZY NL
35 017079 2 FW .250SAE
Fenders, Floor Pan, Footrest & Engine Guard (Multi-Page)
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:28 UTC 2020 3-2
