Item Part No. Qty Name
1 126362-1 1 BRAKE CRANK RIGHT
2 058776 12 NT .312-18NLG5
3 604179 2 BRAKE LINK
4 607078 4 STEERING BUSHING
5 126360-1 1 STEERING BRACKET RIGHT
6 607077 2 STEERING BLOCK A
7 607076 2 STEERING BLOCK B
8 607957-4 2 STEERING LEVER W/A
9 607069 2 STEERING BAR W/A
Not Shown 781260 1 GRIP, STEERING BAR
10 767954 12 FW 0.379X.82X.06 HD ZN
11 036244 4 CS .375-16X1.00 HX G5 ZN
12 086660 4 NT .375-16NLG8
13 023655 2 NT 0.312-24 NL G8
14 126361-1 1 STEERING LINKAGE MOUNT
15 603983 2 DAMPER
16 781922 4 BALL STUD
17 056036 2 CS .375-16X2.250HXG5
18 607938 2 STEERING ROD S/A
19 126359-1 1 STEERING LINKAGE LEFT
20 126358-1 1 STEERING BRKT LH
21 126363-1 1 BRAKE CRANK LEFT
22 126357-6 1 STEERING COVER W/A
23 601982 2 CN .250-20X .150 MAX THK
24 768523 6 FW 0.343SAE
25 601069 3 CN .312-18x.200 MAX THK
26 005108 2 CS .375-16X3.500HXG5
27 765339 4 BUSHING,IGUS#0608 (FS)
28 793315 2 SWITCH, SNAP MOUNT
29 016253 6 CB .312-18X .750 FUL ZN
30 808493 2 RIVET NUT, 3/8-16 THREA
31 706168 2 NT .375-16JAMG5
32 604365 2 CS .375-12X1.50 HX G5 ZN
33 607965 2 BRAKE CABLE
Steering Assembly (Multi-Page)
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:34 UTC 2020 4-5
