Comments for Page: Wheels & Tires
1. Torque to 65–75 ft-lbs.
Item
Part No.
Qty
Name
1
607813
2
TIR/WHL 20X12.00-10 BLK
2
061077
8
WHEEL NUT
3
607831
2
BEARING CAP
4
705954
2
CS .500-13X1.25 HX G5 ZN
5
712976
2
FW 0.531X1.38X.12 ZN
6
784223
4
BEARING
7
784603
2
SPACER
8
N/A
2
REFER TO "FRONT WHEEL ASSEBMLY"
Wheels & Tires
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:35 UTC 2020
5-1
30
32
Table of Contents
Table of Contents
3
General Information
4
Frame
5
Fenders, Floor Pan, Footrest & Engine Guard (Multi-Page)
9
Instrument Panel & Wire Harness
14
Battery
16
Transmissions, Drive Belt, Steering & Brake
18
Transmissions
18
Transmission Service Parts
20
Drive Belt & Clutch
22
Steering & Brake
24
Steering Assembly (Multi-Page)
26
Wheels & Tires Wheels & Tires
30
Front Wheel Assembly
32
Drive Wheel Breakdown
34
Engine, Clutch & Fuel System
36
Engine & Muffler (Multi-Page)
36
Engine Service Parts
42
Fuel System
44
Fuel Tank Service Parts
46
Deck, Deck Belt, Blades & Deck Lift
48
Service Deck
48
Deck Pulleys & Spindles
50
Spindle Service Parts - 607418
52
Deck Belt, Pulley Covers & Blades
54
Deck Lift & Mounting Hardware (Multi-Page)
57
Seat Seat
64
Seat Service Parts
66
