Item
Part No.
Qty
Name
1
604691
1
FORK W/A
2
061101
1
NT .750-10 HX ZN NL GR B
3
025296
2
FW .760X1.63X0.08 ZN
4
041475
1
CS .750-10X9.50 HX G5 ZN
5
605035
1
TIR/WHL 13X6.50-6 BLK
6
604845
2
BEARING, WHEEL SEALED
7
019521
1
TIRE VALVE TR-412 GOODY
Front Wheel Assembly
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:36 UTC 2020
5-2
32
34
Table of Contents
Table of Contents
3
General Information
4
Frame
5
Fenders, Floor Pan, Footrest & Engine Guard (Multi-Page)
9
Instrument Panel & Wire Harness
14
Battery
16
Transmissions, Drive Belt, Steering & Brake
18
Transmissions
18
Transmission Service Parts
20
Drive Belt & Clutch
22
Steering & Brake
24
Steering Assembly (Multi-Page)
26
Wheels & Tires Wheels & Tires
30
Front Wheel Assembly
32
Drive Wheel Breakdown
34
Engine, Clutch & Fuel System
36
Engine & Muffler (Multi-Page)
36
Engine Service Parts
42
Fuel System
44
Fuel Tank Service Parts
46
Deck, Deck Belt, Blades & Deck Lift
48
Service Deck
48
Deck Pulleys & Spindles
50
Spindle Service Parts - 607418
52
Deck Belt, Pulley Covers & Blades
54
Deck Lift & Mounting Hardware (Multi-Page)
57
Seat Seat
64
Seat Service Parts
66
