Item Part No. Qty Name
1 1 ENGINE, KAW FR691V
2 604463 1 HOSE, OIL DRAIN
3 607854 1 MUFFLER
4 767954 4 FW 0.379X.82X.06 HD ZN
5 602580 4 CS .375-16X1.25HXG8ZYP85
6 029876 1 LW .312 INTEXT ZN
7 720516 1 CS M8-1.25X16HX FL10.9
8 606445 1 STARTER SOLENOID
9 768515 4 FW 0.281SAE
10 055939 2 CS .250-20X0.75 HX G5 ZN
11 768523 1 FW 0.343SAE
12 041152 2 NT 0.312-24 HX G8
13 000323 2 CLIP, HOSE CLAMP
14 015818 13" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
15 000331 2 WIRE TIE, SMALL/SHORT
16 603326 25" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
Engine & Muffler (Multi-Page)
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:37 UTC 2020 6-1
