Comments for Page: Fuel System
SEAL/RUBBER STRIP LENGTH
A: 5"
B: 4"
C: 7.5"
VAPOR LINE LENGTH
D: 16.5" TANK TO VAPOR TEE (VAPOR)
Item Part No. Qty Name
1 126202-1 1 YELLOW, TANK MOUNT
2 713198 10 SEAL 3/8x3/4 SOLD BY FT
3 608040 24 RUBBER STRIP
4 055939 1 CS .250-20X0.75 HX G5 ZN
5 768515 1 FW 0.281SAE
6 607745 1 FUEL TANK ASSY
7 607731 1 CAP - 2.25" KELCH
8 603326 16.5 VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
9 000331 1 WIRE TIE, SMALL/SHORT
10 605690 1 TEE, 3/16" PLASTIC
11 605564 1 BOOT, 3/16 TO 3/16
12 604323 1 FILTER, VAPOR SYSTEM
13 000430 1 WIRE TIE, SMALL/LONG
14 604966 2 TRIM LOCK, 1.13"
Fuel System
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:39 UTC 2020 6-3
