1. Torque to 73 ft-lbs.
2. Torque to 30 ft-lbs.
3. Torque to 3–6 ft-lbs.
Item Part No. Qty Name
1 781567 3 NT .500-13NLG5
2 125847-4 1 BELT GUIDE, 4.00" IDLER
3 607428 1 FW 0.531 X 0.90 X 0.134
4 605467 3 DUST SHIELD
5 605512 1 4" IDLER PULLEY
6 604194 1 SLED, IDLER
7 604110 2 ANCHOR, SPRING TENSIONER
8 607616 1 SPRING, DECK IDLER
9 608059 5 NT 0.312-18 FL NY G5
10 604079 2 IDLER SLIDE, EXTRUDED
11 604253 1 CB .50-13 X 2.00 STD ZN
12 705954 3 CS .500-13X1.25 HX G5 ZN
13 798603 3 FW .515X1.65X.12 HD ZN
14 604661 6 SPACER, SPINDLE PULLEY
15 604664 3 PULLEY, DECK DRIVE B-SEC
16 604515 12 NT .375-16 FL NY GF
17 604486 2 FW .531X.812X.089 HD
18 607479 1 IDLER PULLEY, 5.00"
19 605508 2 FW .73X2.25X.31 ZN
20 017129 1 FW .440X1.00X0.08 ZN
21 607480 1 IDLER PULLEY, 4.00"
22 607418 3 BLADE SPINDLE ASSY
23 016253 5 CB .312-18X .750 FUL ZN
24 604254 2 CB .50-13 X 2.50 STD ZN
Deck Pulleys & Spindles
54" Raptor XD Parts Manual - 939751EX - HTRXDS054KAWFR691VE
Fri Oct 09 06:48:41 UTC 2020 7-2
