HUSTLER 939769 - Transmissions

Comments for Page: Transmissions
1. Torque to 17 ft-lbs.
2. Torque to 44 ft-lbs.
3. Left side transmission.
4. Right side transmission.
Item Part No. Qty Name
1 710087 4 CS .312-18X2.500HXG5
2 043067 4 CS .312-18X3.000HXG5
3 768523 16 FW 0.343SAE
4 607746 1 ZT2800, 20.69:1 TRANS
5 607747 1 ZT2800, 20.69:1 TRANS
6 608241 2 CS .375-16X2.250HXG8
7 712919 2 FW 0.406X1.00X.12 HD ZN
8 058776 8 NT .312-18 NL G5
9 607944 2 SPRING, BRAKE BIAS
10 607836 1 TORSION ROD, RSD
11 706549 2 HP0.080X1.190
12 607826-1 2 LINK, TOW VALVE
Transmissions
60" Raptor XD Parts Manual - 939769 - HTRXDS060KAWFR730VA
Wed Nov 10 15:33:10 UTC 2021 5-1
