Comments for Page: Engine & Muffler (Multi-Page)
1. Supplied with the engine.
2. Torque to 30–35 ft-lbs. Replace (do not reuse) the cap screw if it is removed or loosened. Use only hand tools to install this fastener.
3. Torque to 17 ft-lbs.
4. Part of the wire harness.
5. Part of the fuel system.
FUEL & VAPOR LINE LENGTHS
A: 13" TANK TO FUEL FILTER (FUEL)
B: 26" ENGINE TO TEE (VAPOR)
Item Part No. Qty Name
1 1 ENGINE, KAW FR730V
2 604463 1 HOSE, OIL DRAIN
3 607854 1 MUFFLER
4 767954 4 FW 0.379X.82X.06 HD ZN
5 602580 4 CS .375-16X1.25HXG8ZYP85
6 029876 1 LW .312 INTEXT ZN
7 720516 1 CS M8-1.25X16HX FL10.9
8 606445 1 STARTER SOLENOID
9 768515 2 FW 0.281SAE
10 055939 2 CS .250-20X0.75 HX G5 ZN
11 768523 2 FW 0.343SAE
12 041152 2 NT 0.312-24 HX G8
13 000323 2 CLIP, HOSE CLAMP
14 015818 13" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
15 603326 25" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
16 000331 2 WIRE TIE, SMALL/SHORT
Engine & Muffler (Multi-Page)
60" Raptor XD Parts Manual - 939769 - HTRXDS060KAWFR730VA
Wed Nov 10 15:33:18 UTC 2021 7-1
