Comments for Page: Seat
1. Do not torque; the seat pan must pivot freely.
2. Torque to 7 ft-lbs.
3. The seat pan includes the decal.
Item Part No. Qty Name
1 608028 1 SEAT, SK130 W/ RF WELD
2 604307 1 MOUNT, PUSH BUTTON
3 555767 1 SVC, SEAT PAN
4 768523 4 FW 0.343SAE
5 036236 4 CS .312-18X1.000HXG5
6 000331 1 WIRE TIE, SMALL/SHORT
7 086660 2 NT .375-16 G8 NL
8 767954 4 FW 0.379X.82X.06 HD ZN
9 607838 2 CAP
10 029629 2 CS .375-16X0.75 HXF G5ZN
11 793851 2 SPRING,COMP 1.25X4.00X.
12 016899 2 NT .375-16 FLKG5
13 036244 2 CS .375-16X1.00 HX G5 ZN
14 601815 1 DECAL, BATTERY WARNINGS
15 793315 1 SWITCH, SNAP MOUNT
Seat
60" Raptor XD Parts Manual - 939769 - HTRXDS060KAWFR730VA
Wed Nov 10 15:33:28 UTC 2021 9-1
