HUSTLER Fastrak 48 User Manual

REV K 4-12 605596
Figure 4-22
Figure 4-23
Figure 4-24
1. Engine Oil Fill & Dipstick
2. Fuel Filter
3. Engine Air Cleaner
4. Engine Oil Drain Plug
5. Battery
6. Fuel Tank
7. Hydraulic Oil Expansion Tank
8. Hydraulic Oil Filter
9. Front Wheel Bearing Zerks (2)
10. Engine Oil Filter
11. Deck Height Pivot Zerks (4)
12. Park Brake Switch
13. Drive Tire
14. Deck Belt
15. Pump Belt
16. Blades
17. Fuel Evaporation System Filter
14
16
16
16
Side Discharge Deck Shown
13
13
8
8
15
14
16
16
16
Rear Discharge Deck Shown
