HUSTLER Fastrak 48 - Maintenance Locator Chart

605596 4-11 REV K
Maintenance Locator Chart
1. Engine Oil Fill & Dipstick
2. Fuel Filter
3. Engine Air Cleaner
4. Engine Oil Drain Plug
5. Battery
6. Fuel Tank
7. Hydraulic Oil Expansion Tank
8. Hydraulic Oil Filter
9. Front Wheel Bearing Zerks (2)
10. Engine Oil Filter
11. Deck Height Pivot Zerks (4)
12. Park Brake Switch
13. Drive Tire
14. Deck Belt
15. Pump Belt
16. Blades
17. Fuel Evaporation System Filter
Figure 4-20
Figure 4-21
1
2
3
4
5
6
7
7
9
9
10
12
12
17
11
11
Mowers with Kawasaki engines
1
2
3
4
5
6
7
7
9
9
10
12
12
17
11
11
Mowers with Kohler engines
