HUSTLER Fastrak 54 Parts Manual
4
of 1
of 1 rating
94 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Item
Part No.
Qty
Name
1
052860
3
CS .375-16X1.25 HX G5 ZN
2
767954
1
FW 0.379X.82X.06 HD ZN
3
124567-1
1
FLOOR PAN
4
554682
1
SVC FOOT REST
5
602407
1
DECAL, HUSTLER ID
6
029629
2
CS .375-16X0.75 HXF G5ZN
7
118900
1
SPACER, DECK LIFT LINK
Footrest & Floorpan
54" FasTrak Parts Manual - 938712CE - HTFSTS054KAWFR691VC
Thu Feb 18 05:06:56 UTC 2021
3-2
9
11
Table of Contents
Default Chapter
3
Table of Contents
3
General Information
5
Frame, Footrest & Engine Guard
6
Frame
6
Footrest & Floorpan
9
Engine Guard & Hitch
11
Transmissions, Drive Belt, Steering & Brake
13
Transmission Assembly & Drive Belt
13
Transmission Service Parts - 605234
16
Transmission Service Parts - 605235
19
Steering & Brake (Multi-Page)
21
Steering Cover Assembly
25
Steering Box Assembly Breakdown
27
Wheels & Tires
29
Wheel & Tire
29
Front Wheel Assembly Breakdown
31
Drive Wheel Breakdown
33
Engine, Clutch & Fuel System
35
Engine, Muffler & Clutch (Multi-Page)
35
Engine Service Parts
39
Fuel System - S/N 20054500 & HIGHER (Multi-Page)
42
Fuel Tank Service Parts - 607667
45
Fuel System-S/N 18114075 -20054499 (Multi-Page)
48
Fuel System - S/N 18080150-18114074 (Multi-Page)
52
Fuel System - S/N PRIOR to 18080150 (Multi-Page)
56
Fuel Tank Service Parts - 606581
59
Instrument Panel, Wire Harness, Fenders & Battery
61
Instrument Panel & Wire Harness - S/N 20054498 & HIGHER
62
Instrument Panel & Wire Harness - S/N PRIOR to 20054498
64
Fenders & Battery
65
Deck, Deck Belt, Discharge Chute, Blades & Deck Lift
67
Service Deck
67
Deck Pulleys & Spindles - S/N 19104045 & Higher
70
Deck Pulleys & Spindles - S/N PRIOR to 19104045
73
Spindle Service Parts - S/N 20012912 & HIGHER
76
Spindle Service Parts - S/N PRIOR to 20012912
78
Deck Belt, Discharge Chutes, Pulley Covers, & Blades
80
Deck Lift & Deck Mounting Hardware (Multi-Page)
82
Seat & ROPS
85
Seat, Footrest, & Floor Pan (Multi-Page)
85
Seat Service Parts - 607457 - S/N 19019807 & Higher
89
Seat Service Parts - 607095 - S/N Prior to 19019807
91
Rops
93
