Comments for Page: Deck Belt, Discharge Chutes, Pulley Covers, & Blades
1. Torque to 160 N•m.
2. Do not torque; the discharge chute must pivot freely.
3. Torque to 4–8 N•m.
4. Torque to 3–5 N•m.
Item Part No. Qty Name
1 553064 1 SVC, PULLEY COVER RH
2 553065 1 SVC, PULLEY COVER LH
3 602562 2 DECAL, NO SERVICE
4 068551 4 NT .250-20 HXZY NL
5 768515 4 FW 0.281SAE
6 605469 1 DISCHARGE CHUTE
7 602435 1 SPRING, TORSION
8 086660 1 NT .375-16NLG8
9 786483 1 DECK BELT
10 602432 1 PIN, CHUTE
11 781567 5 NT .500-13NLG5
12 767962 3 FW .531 x 1.063 x .175
13 113717 2 PULLER W/A 14.53" C/C
14 042630 2 CS .500-13X6.500HXG5
15 602341 1 WHEEL, ANTI-SCALP
16 602344 1 SPACER, ANTI- SCALP 5.73
17 602338 1 CB .50-13 X 7.50 STD ZN
18 604780 2 WHEEL, ANTI-SCALP
19 602339 2 CB .50-13 X 4.50 STD ZN
20 605376 1 DECK BUMPER
21 079210 2 FW 0.344X1.0X0.06 ZN
22 604251 2 NT .312-18 HXNL JAM G2ZN
23 016253 2 CB .312-18X .750 FUL ZN
24 606251 3 BLADE, 18.50"-H-F-CW
Not Shown 601012 3 BLADE F18.50"-L-F-CW
Not Shown 601124 3 BLADE, 18.50"-L-F-CW
Not Shown 797712 3 BLADE, 18.50"-GAT-F-CW
Not Shown 797704 3 BLADE, 18.50"-MUL-F-CW
25 782474 3 CW .678 X 2.250 X .187
26 781872 3 CS .625-11X1.250HXG5
Deck Belt, Discharge Chutes, Pulley Covers, & Blades
54" FasTrak Parts Manual - 938712CE - HTFSTS054KAWFR691VC
Thu Feb 18 05:07:19 UTC 2021 8-6
