Comments for Page: Transmission Assembly & Drive Belt
1. Torque to 23 N•m.
2. Torque to 135 N•m.
3. Torque to 41 N•m.
Item Part No. Qty Name
1 043067 4 CS .312-18X3.000HXG5
2 768523 16 FW 0.343SAE
3 710087 4 CS .312-18X2.500HXG5
4 605468 1 DRIVE BELT
5 052860 1 CS .375-16X1.25 HX G5 ZN
6 712919 1 FW 0.406X1.00X.12 HD ZN
7 036384 1 SPRING 1/4 COIL PL 1.23
8 605481 1 BUSHING
9 086660 1 NT .375-16NLG8
10 704791 1 FW .781X1.25X.02 ZN
11 781153 2 BUSHING, UHMW
12 025296 1 FW .760X1.63X0.08 ZN
13 601084 1 SB .750X 2.000 SH.625-11
14 025007 1 CS .62511X1.750HXG5
15 607525 1 PULLEY, IDLER
16 600296 1 SPACER, DECK IDLER
17 122722 1 KIT, TENSION ARM
18 016972 1 NT .625-11 HX G5 ZN
19 605235 1 ZT3100, 24.74:1 RH
20 605234 1 ZT3100, 24.74:1 LH
21 058776 8 NT .312-18NLG5
22 016410 2 CS .375-16X2.000HXG5
23 767954 2 FW 0.379X.82X.06 HD ZN
24 600987 1 ZT SPACER TUBE
25 601982 4 CN .250-20X .150 MAX THK
26 768515 4 FW 0.281SAE
27 055939 4 CS .250-20X0.75 HX G5 ZN
28 605217 2 RESERVOIR, SINGLE FTNG
Not Shown 600767 2 CAP, OVERFLOW TANK
29 601001 4 SPRING CLAMP, .75" DIA
30 605218 2 OVERFLOW HOSE, FST
31 120126 2 LINK, TOW VALVE
32 706549 2 HP0.080X1.190
Transmission Assembly & Drive Belt
54" FasTrak Parts Manual - 938712CE - HTFSTS054KAWFR691VC
Thu Feb 18 05:06:58 UTC 2021 4-1
