HUSTLER Fastrak 54 Parts Manual
4
of 1
of 1 rating
94 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Item
Part No.
Qty
Name
1
604691
1
FORK W/A
2
041475
1
CS .750-10X9.50 HX G5 ZN
3
025296
2
FW .760X1.63X0.08 ZN
4
061101
1
NT .750-10 HX ZN NL GR B
5
605197
1
TIR/WHL 13X6.50-6 SLV
6
786103
2
WHEEL BEARING
7
605198
1
WHL 6X4.50 SLV
8
019521
1
TIRE VALVE TR-412 GOODY
9
604843
1
TIR 13X6.50-6 B4R SMTH
10
747741
1
TIR 13X6.50-6 B4R RIB
Front Wheel Assembly Breakdown
54" FasTrak Parts Manual - 938712CE - HTFSTS054KAWFR691VC
Thu Feb 18 05:07:04 UTC 2021
5-2
31
33
Table of Contents
Default Chapter
3
Table of Contents
3
General Information
5
Frame, Footrest & Engine Guard
6
Frame
6
Footrest & Floorpan
9
Engine Guard & Hitch
11
Transmissions, Drive Belt, Steering & Brake
13
Transmission Assembly & Drive Belt
13
Transmission Service Parts - 605234
16
Transmission Service Parts - 605235
19
Steering & Brake (Multi-Page)
21
Steering Cover Assembly
25
Steering Box Assembly Breakdown
27
Wheels & Tires
29
Wheel & Tire
29
Front Wheel Assembly Breakdown
31
Drive Wheel Breakdown
33
Engine, Clutch & Fuel System
35
Engine, Muffler & Clutch (Multi-Page)
35
Engine Service Parts
39
Fuel System - S/N 20054500 & HIGHER (Multi-Page)
42
Fuel Tank Service Parts - 607667
45
Fuel System-S/N 18114075 -20054499 (Multi-Page)
48
Fuel System - S/N 18080150-18114074 (Multi-Page)
52
Fuel System - S/N PRIOR to 18080150 (Multi-Page)
56
Fuel Tank Service Parts - 606581
59
Instrument Panel, Wire Harness, Fenders & Battery
61
Instrument Panel & Wire Harness - S/N 20054498 & HIGHER
62
Instrument Panel & Wire Harness - S/N PRIOR to 20054498
64
Fenders & Battery
65
Deck, Deck Belt, Discharge Chute, Blades & Deck Lift
67
Service Deck
67
Deck Pulleys & Spindles - S/N 19104045 & Higher
70
Deck Pulleys & Spindles - S/N PRIOR to 19104045
73
Spindle Service Parts - S/N 20012912 & HIGHER
76
Spindle Service Parts - S/N PRIOR to 20012912
78
Deck Belt, Discharge Chutes, Pulley Covers, & Blades
80
Deck Lift & Deck Mounting Hardware (Multi-Page)
82
Seat & ROPS
85
Seat, Footrest, & Floor Pan (Multi-Page)
85
Seat Service Parts - 607457 - S/N 19019807 & Higher
89
Seat Service Parts - 607095 - S/N Prior to 19019807
91
Rops
93
