1. **IMPORTANT**
Before replacing Fuel Tank, refer to Service Bulletin 550.
FUEL & VAPOR LINE LENGTHS
A: FRONT RIGHT SIDE PORT TO TEE (VAPOR)
B: ENGINE TO CROSS (VAPOR)
C: TEE TO CROSS (VAPOR)
D: LEFT BACK PORT TO TEE (VAPOR)
E: FILLER NECK PORT TO TEE (VAPOR)
F: RIGHT BACK PORT TO TEE (VAPOR)
G: 31 cm CROSS TO FILTER (VAPOR)
H: 5 cm VALVE TO ENGINE (FUEL)
J: 56 cm TANK TO VALVE (FUEL)
Item Part No. Qty Name
30 016832 1 NT .312-18FLKG5
31 000430 1 WIRE TIE, SMALL/LONG
Fuel System - S/N PRIOR TO 18080150 (Multi-Page)
54" FasTrak Parts Manual - 938712CE - HTFSTS054KAWFR691VC
Thu Feb 18 05:07:12 UTC 2021 6-7
