Comments for Page: Fenders & Battery
1. Part of the Instrument Panel assembly.
2. When performing service on the mower, disconnect the negative battery cable (black) and do not reconnect it to the battery until ready to start the
engine.
3. The battery hold down includes the seal and decal.
SEAL LENGTH
A : 2.5"
Item Part No. Qty Name
1 605558 1 FENDER LID
2 605627 1 CS .250-20 X 1.25 HX
3 605628 8 FW 0.281X.63X.07 ZB
4 601815 1 DECAL, BATTERY WARNINGS
5 601982 3 CN .250-20X .150 MAX THK
6 552858 1 BATTERY HOLD DOWN
7 713198 2.5" SEAL 3/8x3/4 SOLD BY FT
8 605629 1 UNTHREADED PN 0.250 ID
9 605522 1 LH FENDER
Comments for Part Num. 605522
The ‘decal’ which is on this fender is an ‘in-mold label’ and not available for purchase separately.
10 604324 2 CS .250-20 X .75 HX FLG
11 605473 6 CS .250-20X0.75 BH TX BZ
12 605521 1 RH FENDER
Comments for Part Num. 605521
The ‘decal’ which is on this fender is an ‘in-mold label’ and not available for purchase separately.
13 016816 2 NT .250-20FLKG5
14 024927 2 NT .250-20HXG5
15 029868 4 LW .250 INTEXT ZN
16 055939 2 CS .250-20X0.75 HX G5 ZN
17 017079 2 FW .250SAE
18 056077 2 CS .250-20X1.000HXG5
Fenders & Battery
54" FasTrak Parts Manual - 938712CE - HTFSTS054KAWFR691VC
Thu Feb 18 05:07:15 UTC 2021 7-3
