HUSTLER FasTrak SD Service Manual

114242 6-5 REV B
NOTE: The following notes are the same for the four different decks shown.
1. Spring length after tensioning new belt. Measured from outside of hook to outside of hook with deck set at 3¼" cut height.
2. Route belt as shown.
48" Deck Belt Routing & Tensioning
54" Deck Belt Routing & Tensioning
Figure 6-13
8.3” – 9.3”
(210.8mm – 236.2mm)
Figure 6-14
8.3” – 9.3”
(210.8mm – 236.2mm)
