Comments for Page: Instrument Panel - KAWASAKI & KOHLER - S/N 12022042 & HIGHER
1. 603087 is used with Kawasaki and Honda engines.
2. 786657 is used with Kohler engines.
3. 603409 is used with Kawasaki and Kohler engines.
4. 603475 is used with Honda engines.
5. The instrument panel (551399) includes the decal (603916).
Item Part No. Qty Name
1 603087 1 CABLE, CHOKE 64.5"
Not Shown 786657 1 CABLE, CHOKE
2 785808 1 KEY ASSEMBLY
3 045898 1 IGNITION SWITCH
4 603748 1 FUEL DISPLAY/HOUR METER
5 603523 1 KNOB
6 712257 1 INDICATOR LIGHT, RED(FS)
7 601098 2 CB 10-24 X .500 ZYNC
8 776476 1 SWITCH, PTO 6201-321
9 604373 1 RELAY CONTROL MODULE
10 059832 4 NT #10-24 HX NL ZN
11 063198 2 CS #10-24X0.750FLKG5
12 603409 1 CABLE, THRTL 60"
Not Shown 603475 1 CABLE, THRTL 43"
13 704932 2 FW 0.219X.50X.05 ZN
14 000430 1 WIRE TIE, SMALL/LONG
15 603916 1 DECAL, INST PANEL
16 055947 4 CS .250-20X0.50 HX G5 ZN
17 768515 4 FW 0.281SAE
18 551399 1 SVC PART, INST PANEL
19 043570 1 CLIP - HOSE - SINGLE(FS)
20 034280 1 CS .312-18X0.750HXG5
21 768523 2 FW 0.343SAE
22 034272 1 NT .312-18HXG5
23 000331 7 WIRE TIE, SMALL/SHORT
24 603927 1 WIRE HARNESS, X-ONE/SZ
25 114052 1 KIT, CLUTCH CONN. REP.
Instrument Panel - KAWASAKI & KOHLER - S/N 12022042 & HIGHER
Hustler X-ONE Parts Manual
Tue May 19 17:15:27 UTC 2020 7-3
