Comments for Page: Wheel & Tire
1. Torque to 65–75 ft-lbs.
2. 782078 is used on mowers with 48" and 54" decks.
3. 784058 is used on mowers with 60" decks.
Item Part No. Qty Name
1 705954 2 CS .500-13X1.25 HX G5 ZN
2 344267 2 FW .510X2.15X.19 ZN
3 712976 2 FW 0.531X1.38X.12 ZN
4 784223 4 BEARING
5 784603 2 SPACER
6 782078 2 TIR/WHL 24X9.50-12 SLV
Not Shown 784058 2 TIR/WHL 24X12.00-12 SLV
7 061077 10 WHEEL NUT
8 N/A 1 FRONT WHEEL SUB-ASSEMBLY
Wheel & Tire Hustler X-ONE Parts Manual
Tue May 19 17:14:43 UTC 2020 5-1
