HUSTLER X-ONE 930545 User Manual

Comments for Page: 48" Side Discharge - Deck Belt, Discharge Chute, Pulley Covers & Blades
1. Do not torque the nut; the discharge chute must pivot freely.
2. Torque to 118 ft-lbs.
3. Torque to 10 ft-lbs.
4. 781872 is used on mowers S/N 12092657 & higher.
5. 601983 is used on mowers S/N prior to 12092657.
Item Part No. Qty Name
1 113241 2 COVER, PULLEY RH 54"
2 792002 4 KNOB,5/16-18 X 3/4"MALE
3 602429 1 DISCHARGE CHUTE
4 086660 5 NT .375-16NLG8
5 602435 1 SPRING, TORSION
6 602432 1 PIN, CHUTE
7 786483 1 DECK BELT
8 602817 1 RUBBER BUMPER
9 079210 2 FW 0.344X1.0X0.06 ZN
10 064014 2 CS .312-18X0.875HXG5
11 113563 1 BACKING PLATE W/A
12 795757 3 BLADE, F16.50"-H-F-CW
Not Shown 601014 3 BLADE, F16.50"-L-F-CW
Not Shown 601123 3 BLADE, 16.50"-L-F-CW
Not Shown 796623 3 BLADE, 16.50"-MUL-F-CW
Not Shown 796631 3 BLADE, 16.50"-GAT-F-CW
13 782474 3 CW .678 X 2.250 X .187
14 781872 3 CS .625-11X1.250HXG5
Not Shown 601983 3 CS .625-11 X 2.25 HXG5ZN
15 113266 1 WALL, ADJ INNER LH 48"
16 113267 1 WALL, ADJ INNER RH 48"
17 025395 4 CB .375-16X 1.00 G5 ZN
18 767954 4 FW 0.379X.82X.06 HD ZN
48" Side Discharge - Deck Belt, Discharge Chute, Pulley Covers & Blades
Hustler X-ONE Parts Manual
Tue May 19 17:15:33 UTC 2020 8.1-4
