Comments for Page: 60" Rear Discharge - Deck Spindles
1. Torque to 65–75 ft-lbs.
2. 601819 and 601630 are used on mowers S/N prior to 12092657.
Item Part No. Qty Name
37 212472 3 KEY 1/4 SQ X 1.00 LG(FS)
38 045765 2 FW 1.030X1.50X.13 HD ZN
39 016527 12 CS .500-13X1.000HXG5
40 114108 1 SPACER 3/8" THICK
41 607408 1 SPINDLE ASSY, DUCTILE
REF 601819 1 SPINDLE ASSY, 3" PILOT
Comments for Part Num. 601819
Spindle has no service parts available. Replace complete spindle assembly.
42 607407 2 SPINDLE ASSY, DUCTILE
REF 601630 2 SPINDLE ASSY, 3" PILOT
Comments for Part Num. 601630
Spindle has no service parts available. Replace complete spindle assembly.
60" Rear Discharge - Deck Spindles Hustler X-ONE Parts Manual
Tue May 19 17:15:52 UTC 2020 8.5-3
