REV C 7-6 123940
Fuel Line Routing – Kawasaki EFi & Kohler
A. Fuel tank
B. Fuel line
C. Fuel shut-off valve
D. Seat support
Figure 7-14
A
A
C
B
D
Vapor Line Routing – Kawasaki EFi & Kohler
A. Fuel tank
B. Vapor line
C. Tee
D. Fuel evaporation system filter
Figure 7-15
D
C
B
C
A
A
B
