1. Torque to 96–102 N•m.

2. The tensioner must pivot freely.

3. Left side transmission.

Item Part No. Qty Name

1 051151 1 CS .500-13X5.000HXG5

2 344267 1 FW .510X2.15X.19 ZN

3 767954 4 FW 0.379X.82X.06 HD ZN

4 054502 2 NT .375-16HXG5

5 036244 2 CS .375-16X1.00 HX G5 ZN

6 124432-1 1 IDLER SPRING MOUNT

7 781302 1 IDLER SPRING

8 025007 1 CS .62511X1.750HXG5

9 602304 1 PULLEY, 5" FLAT IDLER

10 602880 1 BUSHING, IDLER PIVOT

11 122905 1 TENSIONER W/A

12 015495 1 GREASE FITTING STRAIGHT

13 602879 1 BUSHING, IDLER PIVOT

14 767962 9 FW .531 x 1.063 x .175

15 781567 1 NT .500-13NLG5

16 606411 1 DRIVE BELT

17 023317 8 NT .500-13UNTG8

18 017616 8 CS .500-13X1.750HXG5

19 606401 1 TRANSMISSION, PARKER HTJ

Not Shown 606402 1 TRANSMISSION, PARKER HTJ

Transmissions & Drive Belt

52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
