Item Part No. Qty Name
1 607706 1 SEAT, I3M SEATS INC
2 555027 1 SVC, SEAT PAN
3 605688 1 DECAL, LEVEL FUEL FILL
4 785188 1 DECAL, Z ARMREST WARNING
5 712927 4 FW 0.344X1.00X.12 HD ZN
6 058776 4 NT .312-18NLG5
7 086660 4 NT .375-16NLG8
8 767954 10 FW 0.379X.82X.06 HD ZN
9 052860 3 CS .375-16X1.25 HX G5 ZN
10 724716 1 WASHER, FIBER (FS)
11 350421 1 SEAT PAN STOP (PLATED)
12 036244 1 CS .375-16X1.00 HX G5 ZN
13 601650 2 VIBRATION MOUNT 70DURO
14 054502 2 NT .375-16HXG5
15 785139 1 DECAL, STEERING L.S.
16 554963 1 SVC, FRAME COVER LH - CE
17 601069 5 CN .312-18x.200 MAX THK
18 768523 7 FW 0.343SAE
19 064014 5 CS .312-18X0.875HXG5
20 550824 1 FRAME COVER RS, SERVICE
21 785220 1 DECAL, STEERING R.S.
22 016253 2 CB .312-18X .750 FUL ZN
23 605907 1 LATCH ASSEMBLY
24 601815 1 DECAL, BATTERY WARNINGS
25 034272 2 NT .312-18HXG5
26 000331 2 WIRE TIE, SMALL/SHORT
27 607023 1 DECAL, DECK HEIGHT CE
28 554565 1 SVC, FLOOR PAN
29 118900 1 SPACER, DECK LIFT LINK
Seat & Floor Pan
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:40 UTC 2021 9-1
