Comments for Page: Steering
1. The steering handle includes the grip.
Item Part No. Qty Name
1 N/A 1 REFER TO "STEERING COVER ASSEMBLY"
2 601087 2 SWITCH, PLUNGER N.O.
3 795351 2 DAMPER, CENTERING
4 606521 2 PUMP ROD ASSEMBLY
5 768523 10 FW 0.343SAE
6 023655 4 NT 0.312-24 NL G8
7 605924 2 STEERING BAR W/A
Not Shown 781260 2 GRIP, STEERING BAR
8 767954 8 FW 0.379X.82X.06 HD ZN
9 036244 4 CS .375-16X1.00 HX G5 ZN
10 055822 4 CS .375-16X0.75 HX G5 ZN
11 016899 4 NT .375-16 FLKG5
12 781922 2 BALL STUD
13 029876 2 LW .312 INTEXT ZN
14 016832 2 NT .312-18FLKG5
15 608127 1 DECAL, USA, F&D
16 608098 1 DECAL, X-ONE
Steering
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:20 UTC 2021 4-3
