HUSTLER X-ONE Parts Manual
4
of 1
of 1 rating
72 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Item
Part No.
Qty
Name
1
NSS
2
STEERING ARM W/A
2
086660
3
NT .375-16NLG8
3
767954
6
FW 0.379X.82X.06 HD ZN
4
705178
3
CS .375-16X1.750HXG5
5
781153
2
BUSHING, UHMW
6
348862
2
STEERLEVER BUSHING (PLA
7
797738
1
SS .500-13X2.000SH
8
123305
1
STEERING BOX W/A, LH
9
047456
1
GM .750X.188X1.00X.12
Left Steering Box Assembly
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:22 UTC 2021
4-5
