HUSTLER X-ONE Parts Manual
4
of 1
of 1 rating
72 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Item
Part No.
Qty
Name
1
NSS
1
STEERING ARM W/A
2
086660
3
NT .375-16NLG8
3
767954
6
FW 0.379X.82X.06 HD ZN
4
705178
3
CS .375-16X1.750HXG5
5
348862
2
STEERLEVER BUSHING (PLA
6
797738
1
SS .500-13X2.000SH
7
781153
2
BUSHING, UHMW
8
123306
1
STEERING BOX W/A, RH
9
047456
1
GM .750X.188X1.00X.12
Right Steering Box Assembly
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:22 UTC 2021
4-6
23
25
Table of Contents
Default Chapter
3
Table of Contents
3
General Information
5
Frame & Engine Guard
6
Frame
6
Engine Guard
9
Transmissions, Drive Belt, Steering & Brake
11
Transmissions & Drive Belt
11
Transmission Service Parts
13
Steering
15
Steering Cover Assembly (Multi-Page)
17
Left Steering Box Assembly
20
Right Steering Box Assembly
23
Brake
25
Wheels & Tires Wheels & Tires
27
Front Wheel Assembly
29
Drive Wheel Assembly
31
Engine, Muffler, Clutch & Fuel System
33
Engine, Muffler & Clutch (Multi-Page)
33
Engine Service Parts
37
Fuel System
39
LS Fuel Tank Service Parts
42
RS Fuel Tank Service Parts
45
Instrument Panel, Wire Harness & Battery
47
Instrument Panel & Wire Harness
47
Battery
49
Deck, Deck Belt, Blades & Deck Lift
51
Service Deck
51
Deck Pulleys & Spindles - S/N 20100049 & HIGHER
53
Deck Pulleys & Spindles - SN PRIOR to 20100049
55
Spindle Assembly Service Parts - 607407
57
Deck, Deck Belt & Blades (Multi-Page)
59
Deck Lift & Deck Height (Multi-Page)
63
Seat & ROPS
67
Seat & Floor Pan
68
Seat Service Parts - 607706
69
Rops
71
